LEDDownlightCo-E2 Rd200-16W-840-IP54

Electrical data

Voltage type	AC
Power factor	0.7
Max. system power	16 W
Nominal voltage	220|240 V
Max. inrush current	9.8 A
Inrush time	165
Frequency	50|60 Hz
Max. number of luminaires per miniature circuit breaker B16 (MCB)	71
Max. number of luminaires per miniature circuit breaker C16 (MCB)	71

Photometrical data

Lumen	2240 lm
Colour temperature	4000 K
Luminaire efficacy	140 lm/W
Equivalent to	CFL 2x26W
Colour consistency (SDCM)	4
Colour rendering index (CRI)	> 80

Light technical data

Beam angle	100°
Beam angle	100°
UGR	28

Lifespan

Lifetime (L70)	70000 h
Lifetime (L80)	50000 h
On-/Off-cycles	100000

Capabilities

Dimmability	On-Off

Certificates and standards

Protection class according to IEC 61140	II
Degree of protection (IP)	IP54
Impact strength	IK03
Glow wire test	650°C
IP recessed part	IP54
Risk group (EN 62471)	RG0

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	1%
Input current	0.15 A

Housing colour	White
Finishing	White RAL9003
Optical material	PC
Cover material	PS

Length	220 mm
Width	220 mm
Height/depth	35 mm
Outer diameter	220 mm

Application temperature	25°C
Storage environment	-25|50°C
Operating temperature	-10|45°C
